product features:
Main chip: RTL8188
Supported protocols and standards: IEEE 802.11g, IEEE 802.11b, IEEE 802.11n
Interface type: USB1.1 USB2.0
Frequency range: 2.4-2.4835GHZ
Number of working channels: 14
Data modulation: OFDM / CCK / 16-QAM / 64-QAM
Working mode: centralized control (Infrastructure),equivalent equation (Ad-Hoc)
Transmission rate: 150Mbps (maximum value) t
Spread Spectrum Technology: DSSS (Direct Sequence Spread Spectrum)
Sensitivity @PER: 135M: -72dBm @ 10% PER; 130M: -72dBm @ 10% PER; 108M: -72dBm @ 10% PER; 54M: -72dBm @ 10% PER; 11M: -85dBm @ 8% PER; 6M : -88dBm @ 10% PER; 1M: -90dBm @ 8% PER
RF power: 15dbm (maximum value)
Antenna: 2dBi built-in smart antenna
Transmission distance: varies with environment
Support operating system: Windows XP / VISTA / WIN7 / WIN 8 / MAC / LINUX
Working voltage: DC 5V + -0.2V
